STANDARD EQUIPMENT
| FRAME | Tubular steel 150x100x10 mm |
| SECTIONS | Tubular steel 200x100x8 mm |
| SUPPORTS | Two conical roller bearings, swiveling, with interchangeable crankcase system ma/ag |
| CARRIAGE CONTROL | Double effect jacks with hydraulic spider for working depth regulation |
| DISC AXLE | Square steel 50x50 mm |
| WHEEL AXLE | Square steel 60x60 mm - 6 holes hub |
| SOIL SCRAPERS | Individual adjustable plungers |
| SECTIONS CONTROL | Completely hydraulic |
| BALANCE EQUIPMENT KITO | Hydraulic |
| PICK UP DISCS | On series with soil scrapers |
| Version with discs “Fleaux” type ø 810 mm, thickness 10 mm, disc distance 340 mm |
EDX 2000 SP – 16 discs
| EDX 2000 SP 16 81 | |
| DISCS N. | 16 |
| WORK. WIDTH | 3,00 |
| TRANSP. WIDTH | 2,50 |
| SUPPORTS N. | 8 |
| HP | 180 |
| KG | 3410 |
| DISC DIST. | 340 |
| Ø DISC | 810/10 |
EDX 2000 SP – 20 discs
| EDX 2000 SP 20 81 | |
| DISCS N. | 20 |
| WORK. WIDTH | 3,60 |
| TRANSP. WIDTH | 2,50 |
| SUPPORTS N. | 8 |
| HP | 200 |
| KG | 3980 |
| DISC DIST. | 340 |
| Ø DISC | 810/10 |
EDX 2000 SP – 24 discs
| EDX 2000 SP 24 81 | |
| DISCS N. | 24 |
| WORK. WIDTH | 4,20 |
| TRANSP. WIDTH | 2,50 |
| SUPPORTS N. | 8 |
| HP | 220 |
| KG | 4460 |
| DISC DIST.. | 340 |
| Ø DISC | 810/10 |
EDX 2000 SP – 28 discs
| EDX 2000 SP 28 81 | |
| DISCS N. | 28 |
| WORK. WIDTH | 4,90 |
| TRANSP. WIDTH | 2,50 |
| SUPPORTS N. | 12 |
| HP | 260 |
| KG | 4920 |
| DISC DIST. | 340 |
| Ø DISC | 810/10 |
